Product Advantage
This connector meets stringent electrical specifications verified through environmental testing protocols. The 500 Megohms insulation resistance prevents signal leakage and crosstalk, while the maximum 35 Milliohms termination resistance minimizes power loss and heat generation. The 500V AC dielectric withstanding voltage provides a safety margin well above typical operating conditions, reducing failure risk in voltage transient events. These measurable performance characteristics translate to lower maintenance costs, reduced network downtime, and extended service life compared to connectors lacking documented post-testing specifications, delivering quantifiable ROI for infrastructure investments.
Electrical:
1.Applications: 250V AC max. at 2 Amps.
2.Dielectric withstanding Voltage: 500 Volts AC.
3.Insulation Resistance: 500 Megohms.
4.Termination Resistance: 35 Milliohms max. after enviromental testing.
Mechanical:
1.Cable-to-plug tensile strength-20 lbs [89N] min.
2.Durability: 1000 mating cycles
3.Temperature Range: - 40°C to + 100°C
